Unregistering and Redeploying AWS vSockets

This articles describes how to unregister and redeploy AWS vSockets.

Overview

Sometimes it is necessary to migrate a vSocket to a different VM resource, or reinstall a vSocket on a different VM instance type. You can use the Cato Management Application to unregister an existing vSocket from a site, and then recreate the vSocket and redeploy it on a new VM instance. The configurations and settings for the site are preserved when it is redeployed. You can redeploy vSockets for sites with a single vSocket and for high availability (HA) sites with two vSockets.

Single vSocket Sites

This section discusses how to unregister and redeploy a vSocket for sites with a single AWS vSocket.

Unregistering a Single vSocket

Use the Cato Management Application to unregister the vSocket instance from the site. Once the old vSocket is unregistered, a new serial number (S/N) is automatically generated in the Cato Management Application. You will use the new serial number (S/N) when you redeploy the vSocket.

Note

Note: Make sure the EC2 vSocket instance in AWS is turned off before you unregister the vSocket.


To unregister a single vSocket:

  1. From the navigation pane, select Network > Sites, and select the site.

  2. From the navigation pane, click Site Configuration > Socket, and select the Socket you are unregistering.

  3. Under Actions , click Unregister. The vSocket is now unregistered and a new S/N is generated which you will use when deploying the new vSocket instance.

Deploying a Single vSocket

Use the AWS console to delete the previous instance and then deploy a new one. Make sure to enter the new vSocket S/N displayed in the Cato Management Application in Network > Sites > [site name] > Site Configuration > Socket.

After you complete the deployment, the vSocket automatically connects to the site in the Cato Cloud.

To redeploy a single vSocket:

  1. Select and delete the vSocket instance in AWS under Instances > Delete.

  2. Deploy the vSocket instance either manually or using the AWS marketplace. For more about deploying an AWS instance see Deploying an AWS vSocket Site Manually and Deploying a vSocket Site from the AWS Marketplace, respectively.

  3. Start the AWS vSocket from the EC2 dashboard:

    1. In the navigation menu select Instances > Instances.

    2. Right-click the vSocket instance and choose Start instance.

  4. Confirm the site is running in the Cato Management Application in the Network > Sites page.

High Availability vSocket Sites

This section discusses how to unregister and redeploy a vSocket for sites with a two vSockets in an HA configuration.

You can choose to unregister the primary or the secondary vSocket first.

  • If the primary vSocket is unregistered, a failover takes places to the secondary vSocket.

  • If the secondary vSocket is unregistered, the primary vSocket remains active.

  • If both vSockets are unregistered simultaneously, the site becomes disconnected.

Unregistering High Availability vSockets

Use the Cato Management Application to unregister a vSocket instances from the site, then use the new S/N when you redeploy the new AWS vSocket EC2 instance.

Note

Note: Once the secondary vSocket is unregistered, you can optionally remove High Availability settings from the site and delete the secondary vSocket settings. This converts the site from HA configuration to a single vSocket site.

To unregister a vSocket for an HA site:

  1. From the navigation pane, select Network > Sites, and select the site.

  2. From the navigation pane, click Site Configuration > Socket, and select the Socket you are unregistering.

  3. Under Actions , click Unregister. The vSocket is now unregistered and a new S/N is generated which you will use when deploying the new vSocket instance.

Redeploying High Availability vSocket

Use the AWS console to delete the previous instance for the secondary vSocket, and then deploy a new one. The vSocket automatically connects to the site in the Cato Cloud after you complete the deployment.

When you re-deploy the vSocket, make sure to enter the new S/N from the previous section. You can find the S/N for the site in the Cato Management Application in Network > Sites > [site name] > Site Configuration > Socket. In addition, remember to assign the correct IAM role to the vSocket by selecting the vSocket instance > Security > Attach IAM Role and assign AWS-HA-role.

To redeploy a vSocket for an HA site:

  1. Select and delete the vSocket instance in AWS under Instances > Delete.

  2. Deploy a vSocket instance by using the AWS AMI provided by Cato Support. For more about deploying an AWS instance see Configuring High Availability (HA) for AWS vSockets.

  3. Start the AWS vSocket from the EC2 dashboard:

    1. Start the AWS vSocket from the EC2 dashboard:

    2. Right-click the vSocket instance and choose Start instance.

  4. Confirm the site is running in the Cato Management Application in the Network > Sites page.

Verifying vSocket Connectivity

Once you complete re-deploying the vSocket, you can verify the connectivity status of the vSocket:

  • In Network > Sites all available sites appear. If at least one vSocket is running the site appears as ‘Connected’ under ‘Connectivity Status’.

  • In Network > Sites > [site name] > Site Configuration > Socket you can inspect High Availability configuration and HA readiness. For more about HA Status, see What is Socket High Availability.

  • In Network > Sites > [site name] > Site Configuration > Socket connect to the WebUI of a vSocket. The WebUI should be reachable once the vSocket is running.
