This article is a platform for notifications on recent and planned changes to the Cato GraphQL API schema. It contains news and updates highlighting new capabilities, such as newly released APIs and automation tools.
For information about changes that might require you to update your API client, see Cato API Potentially Breaking Changes and EoL.
The API terms used in this article are explained in What is the Cato API.
For any customers using the Cato API, we recommend that you click Follow to automatically receive email notifications for updates to this article about changes to the API.
For more information about the APIs, see the Cato Networks GraphQL API Reference.
Change: Updated API
Feature Title: Updates to appStats API for application experience metrics
The following new fields for the appStats API are available for application experience metrics to enable programmatic access to user, host, and application performance data:
-
experience_score_level- Aggregated experience score indicator -
ttfb- Time to first byte, measures server responsiveness -
tls_latency- Time for establishing TLS connection -
tcp_latency- TCP connection setup time -
http_latency- End-to-end HTTP request latency -
http_error_rate- Rate of HTTP errors observed
Note: These fields are available only for customers with a DEM license.
Change: New API
Feature Title: API support for managing webhooks, mailing lists, and subscription groups
-
Use the following APIs to assign, replace, update, and remove site licenses via API for single and pooled licenses
- Manage webhook integrations using
createWebhook,updateWebhook,deleteWebhook,webhook,webhookList, andtestWebhook - Manage mailing lists using
createMailingList,updateMailingList,deleteMailingList,mailingList, andmailingListList - Combine webhooks and mailing lists into 'subscription groups using'
createSubscriptionGroup,updateSubscriptionGroup,deleteSubscriptionGroup,subscriptionGroup, andsubscriptionGroupList
- Manage webhook integrations using
For details on the notification management in the CMA, refer to the Notifications KB articles
Change: Updated API
Feature Title: Updates to SplitTunnelPolicyMutations
-
The following APIs have been changed to more accurately align with the feature behavior in the Cato Management Application.
-
These changes apply to all of the mutations for the Split Tunnel policy:
-
Exclude- changed to RouteAllToCatoExcept -
Include- changed to RouteOnlySelected -
Coverage- changed to ConnectionMode -
dnsExclusion- changed to dnsSuffix
-
-
These APIs are currently available as Beta.
Change: New API
Feature Title: API support for managing site bandwidth licenses
-
Use the following APIs to assign, replace, update, and remove site licenses via API for single and pooled licenses
-
Mutation APIs:
-
assignSiteBwLicense- assigns a license to a site -
updateSiteBwLicense- for pooled licenses, updates the bandwidth for a site -
replaceSiteBwLicense- replaces the site license with no downtime -
removeSiteBwLicense- removes a license from a site
-
-
These APIs are currently available as Beta.
Change: New API
Feature Title: API support for querying App Catalog and DLP Content Types
-
App Catalog - Query the data for apps, including Compliance, Security, and CASB Activities:
-
catalogApplicationList- All apps and data -
catalogApplication- Single app
-
-
DLP Content - Query the types of content for the DLP Data Inline Protection rule
contentTypeGroupList
These APIs are currently available as Beta.
Change: New API
Feature Title: API support for secondary vSocket for HA configurations
-
Use the following APIs to set story verdicts, change status, and add comments
-
Mutation APIs:
-
addSecondaryAwsVSocketInputFor AWS vSocket with HA configuration, add a secondary vSocket -
AddSecondaryAzureVSocketInputFor AWS vSocket with HA configuration, add a secondary vSocket
-
-
These APIs are currently available as Beta.
Change: New API
Feature Title: API support for XDR stories and comments
-
Use the following APIs to set story verdicts, change status, and add comments
-
Mutation APIs:
-
addStoryCommentPost comments that help track the story investigation -
analystFeedbackManage Story Actions, such as the story Verdict, Type, and Classification. -
deleteStoryCommentDelete a previously posted comment using the comment ID
-
-
This API is currently available as Beta.
Change: Enhancement for APIs
Feature Title: Set site bandwidth values that include one decimal point (e.g. 1.5 Mbps) for more granular accuracy
-
Use the following APIs to set story verdicts, change status, and add comments
-
Impacted types for APIs:
-
LastMileBwInput -
InterfaceInfo -
SocketInterfaceBandwidthInput
-
-
These API types are currently available as Beta.
Change: Update of Primary value to Primary 1
Feature Title: API Support for IPsec IKEv2 sites
The value retrieved from the InterfaceId field in the accountSnapshot and accountMetrics queries are changing as of the gradual release of support for Active/Active configurations on Jan 12, 2025.
| Old Value | New Value | Notes |
|---|---|---|
| Primary | Primary1 | This change lets us support more than one primary tunnel |
Change: New API
Feature Title: API Support for BGP Peering
-
Use the following APIs to simplify the configuring and monitoring BGP peers for sites
-
Mutation APIs:
-
addBgpPeerAdd a new BGP peer to a site -
updateBgpPeerUpdate settings for an existing BGP peer configuration -
removeBgpPeerDelete a BGP peer configuration for a site
-
-
Query APIs:
-
bgpPeerRetrieve information about a specific BGP peer -
siteBgpStatusShow the current BGP status, including session details and route information
-
-
This API is currently available as Beta.
6 comments
Added these updates:
Added New Mutation API for HA Secondary vSocket
Added New Query APIs for App Catalog and DLP Content Types
Added New Mutation APIs for Site Bandwidth Licenses
Added New Mutation APIs for Webhooks, Mailing Lists, and Subscription Groups
Dear Cato
When will the ability to modify custom categories, including adding entries to them, be available via the API?
Best Regards
